Docker Simple TA

Splunk Cloud
Overview
Details
Docker monitoring designed for simple and small docker environments.

Free and does not require CollectD

This is the technology add-on component which contains the data inputs, parsing and search time knowledge objects. See the "Docker Simple" app for some dashboards that use the data from this technology add-on.

Source code | Feature requests and bugs | My other apps

Background

This TA will collect metrics from the docker host using commands such as docker stats and docker ps.
It is called "docker simple" because it is suited for small, simple docker environments.
I created this app becuase I needed to monitor my home docker environment and I couldn't figure out how to do it in a simple manner.
The app is a fork of this: https://github.com/splunk/docker-itmonitoring/tree/master/ta-dockerstats

If you have docker swarms, use kubernetes or have anything remotely complex then you should instead consider using a different solution, such as:
- Outcold add-on here: https://splunkbase.splunk.com/app/3723/ (Note: this is a paid app)
- CollectD to a HTTP Event Collector input (More info in Marc's 2017 .conf talk at bottom of this page)
- Splunk official: https://github.com/splunk/splunk-connect-for-kubernetes
- Whatever else you can find...

Contents and requirements

This app contains a couple of shell scripts for data collection, some inputs that are disabled by default, some parsing properties and some search-time field extractions.
This app does not require python.
The shell scripts call docker commands and by default these are restricted to root. As such you will need to run the UF as root or come up with your own creative solution (such as using cron and redirecting to a file, or see note below about running in a container).
This TA does not require changing the default container logging agent and reads the JSON logs directly. There is a disabled input to read the default docker logs from the default location of /var/lib/docker/containers/*/*json.log.

Installation

Typically you would run this TA on a universal forwarder, probably via a deployment server. In any case, like most other TA's you should do this:
1. Create an index to receive your data
2. Install this TA onto your Search Head(s),
3. Install this TA and onto your Indexer/s or heavy forwarder/s (That is, if your data goes through a heavy forwarder)
4. Create a local/ folder in this TA
5. Copy default/inputs.conf.example to local/
6. Rename it to "inputs.conf"
7. Edit the file and set:
- Which inputs will not be disabled
- The index to send the data to
- Your desired polling rate
8. Save the TA (if necessary deploy it) and restart the UF.
9. Optionally get and install the pre-canned dashboards in the "Docker Simple" app: https://splunkbase.splunk.com/app/4467/

Collecting metrics from within a container

It is possible to collect metrics from within a docker container if you mount the docker socket like so: -v /var/run/docker.sock:/var/run/docker.sock and also install the docker CLI tools into the container.

Thanks

Thank you to Marc Chéné who did most of the original work on which this TA is based.
Go watch his conf talk here: https://conf.splunk.com/conf-online.html?search=IT123634#/

.

Copyright (C) 2019 Chris Younger
I am a Splunk Professional Services consultant working for JDS Australia (https://www.jds.net.au), in Brisbane Australia.

Third party software

The following third-party libraries are used by this app. Thank you!

Release Notes

Version 1.1.3
Feb. 8, 2021

v1.1.3 - Update docker_simple_inventory.sh script so it no longer includes environment variables (becuase they often include plain text passwords) (Thank you securitypimp)

v1.1.2 - Fix regex for new docker stats format (Thank you JRitzer)

v1.1.0 - Fix bug where containers with no mounts would not appear. (Thank you DVeneziano)

Version 1.1.2
June 16, 2020

v1.1.2 - Fix regex for new docker stats format (Thank you JRitzer)
v1.1.0 - Fix bug where containers with no mounts would not appear. (Thank you DVeneziano)

Version 1.1.1
June 15, 2020

v1.1.1 - Fix regex for new docker stats format (Thank you JRitzer)
v1.1.0 - Fix bug where containers with no mounts would not appear. (Thank you DVeneziano)

Version 1.1.0
Jan. 2, 2020
  • Fix bug where containers with no mounts would not appear. (Thank you Davide Veneziano)
Version 1.0.0
April 16, 2019
